Part#: KRYM-AA24M11
Features
Supports PCIe Gen4 x4, USB4 / Thunderbolt Gen3 x2 with USB 3.2 & USB 2.0 compatibility. Compatible with M.2 sizes 2230, 2242, 2260, and 2280, supporting M Key or B+M Key PCIe (NGFF) SSDs.
- PCI Express Base Specification Rev. 4.0 compliant
- PCI Express M.2 Specification Rev. 1.1 compliant
- Supports PCI Express Link Power Management
- USB 3.2 Specification Rev. 1.0 compliant
- Supports PCIe Gen4 x4
- Supports USB4 / Thunderbolt Gen3 x2 with USB 3.2 & USB 2.0 backward compatibility
- Supports BOT & UASP protocols
- USB Hot Plug supported
- USB4 Specification Rev. 1.0 compliant
- USB Type-C Cable & Connector Specification Rev. 2.1 compliant
- USB Power Delivery Specification Rev. 3.1 (Version 1.3) compliant
- Supports USB Link Power Management
- Supports NVMe Power Management
- NVMe: SCSI Translation Specification Rev. 1.5 support
- NVMe Error Reporting & Recovery support
- S.M.A.R.T. drive monitoring
- NVM Express Base Specification Rev. 1.4c compliant
- Supports M.2 sizes: 2230 / 2242 / 2260 / 2280
- Supports M.2 M Key or B+M Key PCIe SSD (NGFF)
Note: Performance depends on the SSD’s controller and capacity
Specifications
Model: KRYM-AA24M11
Input Interface: USB
Output Interface: M.2
Motherboard Connection: USB
Max Transmission Rate: 40 Gbps
Included Accessories: Type-C to Type-C cable
Dimensions: 115.5 × 58.5 × 15 mm
System Requirements
- Windows®, macOS®, Linux®
Package Contents
- USB4 / Thunderbolt to PCIe Gen4 x4 NVMe 40Gbps Enclosure
- Type-C to Type-C cable
User manual
