Part#:
0.5 meter / 50cm – FC-LCLC-D-MM4-0.5M
1 meter – FC-LCLC-D-MM4-1M
2 meter – FC-LCLC-D-MM4-2M
3 meter – FC-LCLC-D-MM4-3M
5 meter – FC-LCLC-D-MM4-5M
10 meter – FC-LCLC-D-MM4-10M
Features
- Designed for data communication networks, local area networks (LANs), and subscriber transmission systems
- Constructed with Kevlar strength members, aramid yarns, and a flame-retardant LSZH (Low Smoke Zero Halogen) outer jacket for enhanced durability and safety
- 100% factory-tested to ensure performance and compliance with all specifications
- Each cable includes an identification label with detailed insertion loss information
- Multimode OM4 LSZH duplex cable for high-performance optical transmission
- Supports data rates of:
- 100 Gbps up to 150 meters
- 10 Gbps up to 550 meters
- 1 Gbps up to 1000 meters
Specifications
- Connector Type: LC/UPC – LC/UPC (Other connector types available on request)
- Fiber Type: 50/125 µm OM4, Multimode
Cable Construction: Duplex (Zipcord) - Buffer Size: Ø0.9 mm and Ø0.6 mm buffered fiber, LSZH (Low Smoke Zero Halogen) jacket
- Polish Type: UPC (Ultra Physical Contact)
- Insertion Loss: ≤ 0.25 dB
- Return Loss: ≥ 30 dB
- Repeatability: ± 0.1 dB
- Operating Wavelength: 850 nm / 1300 nm
- Operating Temperature Range: -10°C to +70°C
- Available Lengths: 0.5 m, 1 m, 2 m, 3 m, 5 m, 10 m (Custom lengths available)
Compliance: ISO/IEC 11801, TIA/EIA-568, IEC 60793-2-10, IEC 61754-20, RoHS
