Part#:
0.5 meter / 50cm – FC-LCLC-D-SM2-0.5M
1 meter – FC-LCLC-D-SM2-1M
2 meter – FC-LCLC-D-SM2-2M
3 meter – FC-LCLC-D-SM2-3M
5 meter – FC-LCLC-D-SM2-5M
10 meter – FC-LCLC-D-SM2-10M
Features
- Ideal for long-distance data transmission in telecommunications, data centers, and enterprise networks
- Constructed with Kevlar strength members, aramid yarns, and flame-retardant LSZH (Low Smoke Zero Halogen) jacket for enhanced durability and safety
- 100% factory-tested to ensure low insertion loss and high return loss performance
- Each cable includes an identification label with detailed insertion loss information
- Single Mode OS2 LSZH duplex cable designed for high-speed, high-bandwidth applications
- Supports data rates of:
- 10 Gbps up to 10 kilometers
- 40/100 Gbps up to 10 kilometers (with appropriate transceivers)
- Fully compliant with ITU-T G.652.D standard for reduced water peak and low attenuation
Specifications
- Connector Type: LC/UPC – LC/UPC (Other connector types available on request)
Fiber Type: 9/125 µm OS2, Single Mode - Cable Construction: Duplex (Zipcord)
Buffer Size: Ø0.9 mm and Ø0.6 mm buffered fiber, LSZH (Low Smoke Zero Halogen) jacket - Polish Type: UPC (Ultra Physical Contact)
- Insertion Loss: ≤ 0.3 dB
- Return Loss: ≥ 50 dB
- Repeatability: ± 0.1 dB
- Operating Wavelength: 1310 nm / 1550 nm
- Operating Temperature Range: -10°C to +70°C
- Available Lengths: 0.5 m, 1 m, 2 m, 3 m, 5 m, 10 m (Custom lengths available)
- Compliance: ITU-T G.652.D, IEC 60793-2-50, IEC 61754-20, RoHS
